Heavy Duty Pillar Drill - B 24H
Categories: Workshop Equipment , Drills , Pedestal / Pillar / Floor Drill , Workshop Equipment , Metalworking , Metalworking , Drills
A heavy duty upright pillar drill with V-belt drive for smooth, precise results. Ideal for design & technology workshops in schools.
Top Key Features
- Smooth and powerful industrial electric motor
- Separate emergency stop impact switch
- Stable casting column
- Depth stop
- Drilling table 360° rotatable
- V-belt cover with safety switch
- V-belt quick clamping device...
Overview
Ideal for D&T Workshop the B24H heavy duty pillar drill is a robust drill that comes with a V-belt drive and delivers smooth, precise results.
Key Features
- Smooth and powerful industrial electric motor
- Separate emergency stop impact switch
- Stable casting column
- Depth stop
- Precisely machined drill table with diagonal T-slots and circumferential cooling water channel
- Drilling table 360 ° rotatable
- V-belt cover with safety switch
- V-belt quick-clamping device
- Long, ergonomic cast aluminum sleeve lever cast in one piece (B 16H / B 24H with softgrip handles)
- Massive, large base plate with grooves, strongly ribbed on the back
- By swinging away the drilling table, base plate can be used as a work surface for particularly high workpieces
- Guaranteed concentricity measured better than 0.015 mm in the drill quill
- Drill spindle with precision ball bearings
- High-quality OPTIMUM keyless chuck in the standard scope of delivery
- Large, height-adjustable protective screen with safety switch
- Machine light
- 400V has forward / reverse operation
Dimensions
Length: | 670 mm |
---|---|
Width: | 440 mm |
Height: | 1000 mm |
Weight: | 92 kg |
Table Size: | 280 x 300 mm (L x W) - drilling |
Base Size: | 280 x 260 mm (L x W) - Stand work surface |

Technical Specifications
Column Diameter: | 80 mm |
---|---|
Drilling Capacity / Performance: | 26 mm - Cast Iron 24 mm - Steel 20mm - Continuous drilling steel |
Drilling Depth: | 85 mm (Max) |
Motor: | 850W - Motor Power |
No. Speeds / Number of gears: | 7 Steps |
Spindle Speed: | 350 - 4,000 rpm |
Spindle Stroke: | 85 mm |
Spindle Taper / Chuck / Seat: | 2MT |
Stand: | Slot size: 14mm Number of slots: 2 Slot distance: 120 mm |
Throat Depth: | 165 mm - spindle to column |
T-slot Size: | 14 mm |
